Swallow
ultralight, ultra lite aircraft, amateur built, experimental,
homebuilt aircraft.
|
|
The Swallow Aeroplane Company
produce the Swallow B in the late 70's to
the early 80's. It is a wire braced single
place, high wing, tractor in a tricycle gear
configuration with a steerable nosewheel.
|
The Swallow uses aluminum
tube bolt together construction, and the
surface wing and tail are covered in dacron
sail cloth.
Controls on the Swallow are joy stick and
rudder pedals and the wings had a trailing
edge wing warping system rather than true
ailerons.The empty
weight of the planes brought into Canada was
close to 300 lbs when equipped with the
Cayuna 430 R engine. |
|
Swallow ultralight, amateur
built, experimental, homebuilt aircraft
|
|
Specifications |
|
|
Empty Weight: |
234 lbs. |
| Gross Weight: |
475 lbs. |
| Wing Span: |
32 ft. |
| Wing Area: |
160 sq.ft |
| Engine:
|
440 Kawasaki |
| Cruise Speed: |
35 .mph |
| Stall Speed: |
25 .mph |
| VNE: |
65 .mph |
| Construction: |
Aluminum tube/dacron/bolt together |
| Building time: |
75 .hrs |
