Hirth F 30 on Para-ski powered parachute.

Hirth F-30 ES Fuel Injected 110 HP

The Hirth F-30S is the high performance version of the F30 80hp engine. F30ES is the F30S engine equipped with fuel injection. With nearly l hp to every pound the F30 has one of the highest power to weight ratios available.

F30ES shown in free air version with fuel injection and G-40 gearbox.



Factory recommended TBO is rated at 1000 Hrs. @ 75% power.

The F-30 incorporates Al-Nikasil coated cylinders for superior performance and reliability. Al-Nikasil in simple terms is a nickel based material, applied in a paste form, when super heated it becomes part of the cylinder itself.

Al-Nikasil provides for a super low coefficient of friction, reducing engine heat and wear. The pistons and cylinders expand at the same rate thus providing for a seizure resistant engine.

F-30 crankshaft is 4130 chromoly steel. Heads, cylinders, rings, block casting, connecting rods and associated components are all of the highest grade alloys available.

Model:

 F-30S/F-30ES

Carburation:

 Dual integral pumper-F30S. Electronic fuel injection-F30ES

Engine Type:

 2 cycle, four cylinder

Fuel Pump:

 Optional auxiliary external pneumatic /Electric on fuel injected ES

Bore:

 72mm

Lubrication:

 Fuel mixed with oil @ 50:1

Stroke:

 64mm

Rotation:

 Counter clockwise, viewed from output end

Displacement:

 1042cc

Starter:
Alternator:

 12 volt electric, recoil optional
250 watt/20 amp alternator standard

Compression:

 9.5:1

Cooling:

 Free air, optional twin fan cooling

F-30ES Fuel Injected

F-30S Carburated :

 110Hp@6200rpm 105HpW/fan cooling

100Hp@6200rpm 95Hp W/fan cooling

Weight:

 105 lbs, including starter and complete exhaust, 129lbs with gearbox, full exhaust, and electric start. Fan cooling adds 8.5 lbs.

ES Torque:

 89ft/lbs @ 5700rpm

Reduction Units:

 G-40 gearbox available in 2.03:l, 2.25:l, 2.64:l, 2.96:l and 3.33:1 ratios.(centrifugal clutch optional) (Optional cogbelt drive also available)

Ignition:

 Dual CDI
(Capacitive digital Ign.)

Drive Coupling:

 Elastomeric dampener or centrifugal clutch
Recreational Power Engineering 5479 E. Co. Rd. 38, Tiffin, Ohio 44883
 419-585-7002
